Home > Products > Stepper Motor > DC Motor Brushless DC Motor Brushless Motor BLDC Motor Brushed Motor Electric Motor PMDC Motor NEMA23 1.8° 57hy2A41- 046 Stepping Motor Stepper Motor
DC Motor Brushless DC Motor Brushless Motor BLDC Motor Brushed Motor Electric Motor PMDC Motor NEMA23 1.8° 57hy2A41- 046 Stepping Motor Stepper Motor
Product DescriptionModel:57hy2A41-046Holding Torque:30N.cmCurrent:0.38AResistance:32ΩMotor Length:41MMWeight:450gMotor are available with different winding and mechanical modification to meet specific applications.ModelHolding Torque (N·cm±10%)Current/Phase(A)Resistan......
Send Inquiry
Product Description
Product Description
Model:57hy2A41-046
Holding Torque:30N.cm
Current:0.38A
Resistance:32Ω
Motor Length:41MM
Weight:450g
Motor are available with different winding and mechanical modification to meet specific applications.
Model:57hy2A41-046
Holding Torque:30N.cm
Current:0.38A
Resistance:32Ω
Motor Length:41MM
Weight:450g
Motor are available with different winding and mechanical modification to meet specific applications.
| Model | Holding Torque (N·cm±10%) | Current/Phase(A) | Resistance/Phase (ohms±10%) | Inductance/Phase (mH±20%) | Detent Torque (N·cm) | Rotor Inertia (g-cm 2 ) | Length (mm) | Weight (g) |
| 57HY2A41-046 | 30 | 0.38 | 32 | 30 | 3.5 | 60 | 41 | 450 |
| 57HY2A41-164 | 22 | 1.55 | 1.8 | 3.5 | 3.5 | 60 | 41 | 450 |
| 57HY2A41-214 | 32 | 2.1 | 0.8 | 1.4 | 3.5 | 60 | 41 | 450 |
| 57HY2A41-156 | 24 | 1.5 | 1.5 | 1.4 | 3.5 | 60 | 41 | 450 |
